Liquid level measurement, interface measurement, suitable for food and chemical industry
| AHL-6100C | |
| Application | Liquid level measurement, interface measurement, suitable for food and chemical industry |
| Range | Rod type: 4m (due to transportation) Cable type: up to 32 meters |
| Probe/material | Rod type, cable/SS 316L, PFA coated |
| Connection type/material | Threaded, flanged or other sanitary connections |
| Temperature | -200…+450°C |
| Pressure | -l...+400bar/-100...+40000kPa |
| Measurement Accuracy | ±lmm |
| Output | • 4...20mA/HART-two-wire system • 4...20mA/HART-four-wire system • Profibus PA • Foundation Fieldbus • Modbus-, Levelmaster-protocol |
| Safety Certification | • ATEX Explosion Permit • IEC Explosion Permit • Marine Permit • Spill Containment • FM • CSA • Gost |
